  More stable, smaller, more convenient design gives more possibilities. Waterproof battery cable Max Outer Diameter 15mm Customized solutions Copper alloy plated Battery connector  description Rated Voltage 48V AC/DC Rated Current 25A Withstanding Voltage 700V Insulation Resistance ≥20MΩ Contact Resistance ≤10mΩ Mating Type Insertion Force 80N Max,Extraction Force 30N Min Mating Cycles 200Times Operation Temperature -25℃~+80℃ Protection Degree IP67 Max Outer Diameter 15mm Mating Length 51mm Contact Material Copper alloy plated with gold which conforms to military standard Wire Section 2.5mm² We are professional high-quality Battery connector manufacturer .We provide you with Variety of connectors ， such as   High-power Battery connecto r  .

  More stable, smaller, more convenient design gives more possibilities. Waterproof battery cable Max Outer Diameter 9mm Customized Battery connector  description Rated Voltage 48V AC/DC Rated Current 15A Withstanding Voltage 700V Insulation Resistance ≥20MΩ Contact Resistance ≤10mΩ Mating Type Insertion Force 80N Max,Extraction Force 30N Min Mating Cycles 200Times Operation Temperature -25℃~+80℃ Protection Degree IP67 Max Outer Diameter 9mm Mating Length 61mm Contact Material Copper alloy plated with gold which conforms to military standard Wire Section 1.0mm²+0.14mm² We are professional Waterproof battery cable factory  .We provide you with   reliable Battery connector  .

  Customized Signal connector Fool Proof Design Different Modelling bike Signal connector  description Rated Voltage 48V AC Rated Current 2A Withstanding Voltage 500V Insulation Resistance ≥20MΩ Contact Resistance ≤10mΩ Mating Type Insertion Force 80N Max, Extraction Force 30N Min Mating Cycles 200Times Operation Temperature -25℃~+80℃ Protection Degree IP66 Max Outer Diameter 9.5mm Mating Length 55mm Contact Material Copper alloy plated with gold which conforms to military standard Wire Section 0.14mm²/ 0.20mm² We are professional Signal connector manufacturer .

  More stable, smaller, more convenient design gives more possibilities. MINI B Signal connector Waterproof signal cable Customized Signal connector  description Rated Voltage 48V AC Rated Current 2A Withstanding Voltage 500V Insulation Resistance ≥20MΩ Contact Resistance ≤10mΩ Mating Type Insertion Force 80N Max, Extraction Force 30N Min Mating Cycles 200Times Operation Temperature -25℃~+80℃ Protection Degree IP66 Max Outer Diameter 9mm     Mating Length 62mm Contact Material Copper alloy plated with gold which conforms to military standard Wire Section 0.14mm²/ 0.20mm² We are professional MINI B Signal connector manufacturer .
